The SIP HG2001DA ARC Inverter Welder is a powerful multi-functional inverter with a lightweight, compact design for portability, and is generator-friendly meaning it is ideal for a variety of applications and environments without mains electricity supplies.
Supplied with electrode holder and cable, plus Earth cable and clamp accessories.
Key Features:
- Output Current Range: 20A to 200A with a 200A @ 60% duty cycle.
- Lift-TIG Start Function: Provides ease of use with anti-stick circuitry to prevent electrode sticking.
- Voltage Reduction Device (VRD): Ensures safety by reducing the voltage when the welder is not in use.
- Thermal Overload Protection: Protects the machine from overheating, ensuring durability and longevity.
- Generator-Friendly: Can be used in all environments, including those without mains electricity.
Technical Specifications:
- Input Supply: 230V (32A)
- Output Voltage: 20.8V – 28V (ARC), 10.8V – 18V (TIG)
- Duty Cycle:
- At 20°C: 200A @ 60%
- At 40°C: 200A @ 15%
- Electrode Diameter: Ø 1.6mm – 5mm
- Welding Thickness: 1.5mm – 9mm
- Open Circuit Voltage: 69V
- Power Factor: 0.75
- Efficiency Level: 85%
- Protection Level: IP21S
- Insulation Class: Class H
- Net Weight: 6.50kg
- Gross Weight: 8.90kg
- Dimensions: 345(H) x 450(W) x 245mm(D)
The SIP HG2001DA ARC Inverter Welder comes complete with an electrode holder and cable, as well as Earth cable and clamp accessories. This welder is designed to provide reliable performance and safety in demanding conditions.
